4,000 psi cold working pressure through 4-inch sizes; 2,500 psi cold working pressure, 5 through 12-inch sizes
Recommended service：
Manifold line connections, pump suction, and mud services
Features：
1. 2-1/2 through 12-inch sizes have O-rings for primary seal
2. Butt-weld available
3. Available for sour gas service
| Nominal pipe size | Total length | Countersink | Nut radius | Material | Weight | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| in | mm | in | mm | in | mm | in | mm | nut | subs | Ibs | kgs |
| 2 | 50.8 | 5 3/16 | 131.8 | 1/4 | 6.4 | 3 9/16 | 90.5 | SF | SF | 11.0 | 5.0 |
| 3 | 76.2 | 6 1/4 | 158.8 | 3/8 | 9.5 | 4 3/16 | 106.4 | SF | SF | 19.25 | 8.7 |
| 4 | 101.8 | 8 1/8 | 206.4 | 3/8 | 9.5 | 5 | 127.0 | SF | SF | 32.0 | 14.5 |
