We supply mud pump and pump parts. The Chinese F series mud pump can meet the requirement of the same manufacturing technique and quality level as those of F series mud pump of EMSCO. We can also supply mud pump parts.
• Pump made in china, for example, F pump etc, and the pumping set in skid respectively.
Pumping set option:
Diesel engine made in china + belt
Diesel engine made in china + hydraulic couplers
•Alternative spare parts for F Pump made in china 85% alternative spare parts could be provided with lower price, except the machining one.
•Mud pump spare parts of abroad brand:
Eg. Liner, piston, valve assembly, valve seat, valve spring, valve rubber could be alternative for original with lower price.
• Original brand:
Emsco、Gardner-Denver, National oilwell, Ideco, Brewster, Drillmec, Wirth, Ellis, Williams, OPI, Mud King, LEWCO, Halliburton, SPM, Schlumberger, Weatherford
| Serial | F-500 | F-800 | F-1000 | F-1300 | F-1600/1600L | F-1600HL |
|---|---|---|---|---|---|---|
| Max Liner (mm) | 6 3/4*7.5 | 6 3/4*9 | 6 3/4*10 | 7*12 | 7*12 | 7 1/2*12 |
| R/min | 165 | 150 | 140 | 120 | 120 | 120 |
| Kw (HP) | 373 | 597 | 746 | 969 | 1193 | 1193 |
| Gear Type | 4.286:1 | 4.185:1 | 4.207:1 | 4.206:1 | 4.206:1 | 4.206:1 |
| Pinion shaft diameter (mm) |
5 1/2 | 7 | 7 3/4 | 8 1/2 | 8 1/2 | 8 1/2 |
| KGS | 9770 | 14500 | 18790 | 24572 | 24791/25900 | 29400 |
